| 29 |
5.5 Finish cutting process
DANGER
Risk of injury due to an uncontrolled recoil of the
wall chaser, caused by canting of the wall chaser in
the cut chase.
Î Always wait for the cutter to stop completely
before removing the wall chaser from the cut
chase.
•
7
The wall chaser switches off as soon as the
pressure on the control handle (4) in the direc-
tion of cutting is reduced.
• Do not remove the wall chaser from the chase
and put it down until the cutter has completely
stopped rotating.
6 Cleaning
DANGER
Risk of fatal injuries due to electric shock.
Î Disconnect the mains plug before carrying out
any work on the wall chaser.
The machine must be cleaned after each cutting
work session.
• Clean the machine carefully.
• Ensure handles are dry and free from grease.
7 Maintenance
DANGER
Risk of fatal injuries due to electric shock.
Î Disconnect the mains plug before carrying out
any work on the wall chaser.
The wall chaser must be serviced at least once a
year. Further, servicing will be necessary depending
on the wear of the carbon brushes.
Only servicing and repair firms authorised by
Maschinenfabrik OTTO BAIER GmbH may car-
ry out maintenance of the machine. Also ensure
that original BAIER spare parts and original BAIER
accessories only are used.
8 Tools and Accessories
•
BAIER special dust extractor
(Id. No. see BAIER Catalogue)
• Aluminium discs (10) (Id. No. 3657)
• Dust extractor cover (Id. No. 47084)
BAIER cutters ID. No.
Chase
depth
[mm]
Chase
width
[mm]
Euro cutter 20 55657 23 – 35 20
Euro cutter 25 54650 25 – 38 25
Cutter 4 30866 23 – 35 13
Cutter 318 31062 23 – 35 18
Cutter 67 12088 23 – 35 30
Cutter 67 for
sand-lime
(calcium silicate)
brick
12096 23 – 35 30
9 Disposal
Recycle the machine and its packaging
in an environmentally friendly way in
accordance with the provisions applicable
in your country.
10 Scope of Supply
Please refer to the enclosed delivery note for the
individual scope of supply of a customer- specific
order.
Please refer to the table below for the scope of
supply of basic models. Please contact your dealer
if parts are missing or damaged.
Wall Chaser
Basic selection ld. No.
Dust
extraction
Euro
cutter 25
BMF 501
59568 x
67207 x x
x included in scope of supply
