Approach Autograph Dimensional Data Table
MODEL Autograph 625 Autograph 740 Autograph 745 Autograph 750 Autograph 765
Base Vehicle Manufacturer Peugeot Peugeot Peugeot Peugeot Peugeot
Chassis AL-KO AMC AL-KO AMC AL-KO AMC AL-KO AMC AL-KO AMC
Base Vehicle Model 335 335 335 335 335
Wheel Base Length 4200 mm 4102 mm 4102 mm 4700 mm 4700 mm
Overall Length 6640 mm 7450 mm 7450 mm 7450 mm 7450 mm
Overall Width (mirrors extended) 2770 mm 2770 mm 2770 mm 2770 mm 2770 mm
Overall width (mirrors folded) 2412 mm 2412 mm 2412 mm 2412 mm 2412 mm
Overall Height 2785 mm 2785 mm 2785 mm 2785 mm 2785 mm
Double Bed Transverse - 1224 x 2250 mm 1210 x 2240 mm 1077 x 1840 mm 1030 x 1840 mm
Drop Down Bed (Where tted) - - - - 1230 x 1835 mm
Fixed Bed (Where Fitted) - 1980 x 1350 mm 1980 x 1350 mm - -
Rear N/S Double 2210 x 1800 mm - - - 2200 x 1800 mm
Rear N/S Single 1800 x 710 mm - - 780 x 1780 mm 1800 x 710 mm
Rear O/S Single 1800 x 710 mm - - 780 x 1780 mm 1800 x 710 mm
Fresh Water Tank Capacity (Litres) 100 100 100 100 100
Waste Water Tank Capacity (Litres) 100 100 100 100 100
Gas Butane (Depending on
Manufacturer)
2 x 10 Kg 2 x 10 Kg 2 x 10 Kg 2 x 10 Kg 2 x 10 Kg
Gas Propane (Depending on
Manufacturer)
2 x 10 Kg 2 x 10 Kg 2 x 10 Kg 2 x 10 Kg 2 x 10 Kg
