Bailey Approach - Page 15

13
SERVICE MANUAL
4
Weights and Dimension Data
Approach Compact Weight Data Table
MODEL Compact 520 Compact 540
Engine 2.2 Hdi 2.2 Hdi
Vehicle Designation 335 335
MTPLM 3500 Kg 3500 Kg
Mass in Running Order (MRO) 2737 Kg 274 1 Kg
User Payload 763 Kg 759 Kg
Conventional Load (75 Kg per
person)
225 Kg 225 Kg
Designated Passenger seats
(Excluding Driver)
3 3
Essential Habitation equipment 129 Kg 129 Kg
Gross Train Weight 5500 Kg 5500 Kg
MBTM 2000 Kg 2000 Kg
Maximum Tow ball nose weight 80 Kg 80 Kg
Axle Weights
Front Axle Weight, in running
order
1452 Kg 1446 Kg
Rear axle weight, in running
order
1129 Kg 1139 Kg
Front Axle Limit 1850 Kg 1850 Kg
Rear Axle Limit 2000 Kg 2000 Kg
