Approach Compact Dimensional Data Table
MODEL Compact 520 Compact 540
Base Vehicle Manufacturer Peugeot Peugeot
Chassis AL-KO AMC AL-KO AMC
Base Vehicle Model 335 335
Wheel Base Length 3731 mm 3731 mm
Overall Length
Overall Width (mirrors extended) 2770 mm 2770 mm
Overall width (mirrors folded) 5999 mm 5999mm
Overall Height 2785 mm 2785 mm
Double Bed Transverse
Drop Down Bed (Where tted) 1950x1540 mm
Fixed Bed (Where Fitted) 2020 x 1370 mm
Front Transverse bed
Rear N/S Single
Rear O/S Single
Fresh Water Tank Capacity (Litres) 90 Litre
Waste Water Tank Capacity (Litres) 90 Litre
Gas Butane (Depending on
Manufacturer)
2 x 10 Kg 2 x 10 Kg
Gas Propane (Depending on
Manufacturer)
2 x 10 Kg 2 x 10 Kg
