Engine 4 stroke, Natural air cooled 4 stroke, Natural air cooled
Bore x Stroke 47 mm x 58.8 mm 50 mm x 58.8 mm
Displacement 102 cc 115.45 cc
Idling Speed 1400 +/- 100 rpm 1400 + 100 rpm
Max. Net Power 7.9 PS @ 7500 rpm 8.6 PS @ 7000 + 250 rpm
Max. Net Torque 8.34 Nm @ 5500 rpm 9.81 Nm @ 5000 + 250 rpm
Ignition System DC CDI DC, CDI
Starting Aid Kick / Self Kick / Self
Spark Plug (2 nos.) Champion or BOSCH Champion or BOSCH
Spark Plug Gap 0.7 to 0.8 mm 0.7 to 0.8 mm
Transmission 4 speed (All down) 4 Speed (All down) Drum-Drum
5 Speed (All down) Disc-Drum
Lubrication Force Lubrication Force Lubrication
Front Brake Drum Drum-Drum / Disc-Drum
Rear Brake Drum Drum
Tyre Front 2.75 X 17”, 41P 80/100-17, 46P, Tubeless
Tyre Rear 3 X 17”, 50P 80/100-17, 53P, Tubeless
Platina 100 Platina 110
Technical Specifications
