WATER CONNECTIONS:
Do not connect the cold and hot water pipe lines directly to the heater. Instead, connect them using flexible tubes of
appropriate material. Never use plastic tube especially at the outlet because it cannot withstand the heat. In case of
direct pipe connections, tightening of couplings using a wrench can damage the heater unit. USE A CONTROL VALVE
AT THE INLET. MAKE SURE THAT IT IS ALWAYS KEPT OPEN.
Technical Specification Table. Check where your Storage Water Heater Fits in.
(Ref fig. 2, 3, 4 & 5)
Overall Dimensions Model
Capacity
(in litres)
Element
Rating
(in Kw)
Time required
to raise the
Temp. by
35
o
C
(in minutes)
Weight of
Water
Heater
(in kgs)*
Pipe
Connection
(in BSP)
A
B
C
D
E
Powder Coated Vertical Models
Colours
EE 6 6 3.0 8 13.50 1/2" 174
185
370
228
15
EE 10 10 3.0 12 16.03 1/2" 214
195
445
264
14
EE 15 15 2.0 20 29.00 1/2" 214
235
475
303
14
EE 25 25 2.0 30 36.00 1/2" 214
385
663
303
14
EE 25
Dwarf
25 2.0 30 36.50 1/2" 214
260
540
355
14
EE 35 35 2.0 55 50.00 1/2" 214
335
650
355
14
EE 15
Designer
15 2.0 20 29.00 1/2" 214
234
488
332
14
EE 25
designer
25 2.0 30 36.00 1/2" 214
384
650
332
14
Powder Coated Horizontal Models**
EE 15 15 2.0 20 28.50 1/2" 214
235
475
303
14
EE 25 25 2.0 30 38.50 1/2" 214
385
663
303
14
EE 35 35 2.0 55 50.00 1/2" 214
335
650
355
14
Stainless Steel Vertical Models
EE 15 15 2.0 20 29.00 1/2" 214
235
475
303
14
EE 25
Dwarf
25 2.0 30 36.50 1/2" 214
260
540
355
14
All
models
are
available
in
following
colours:
Ivory,
White,
Maroon,
Blue,
Pink,
Grey.
* When completely filled with water
** Horizontal models are available in Floor and Wall mounting configurations.
These can be easily converted from Wall mounting to Floor mounting and vice versa.
Due to continuous efforts for improvement, specifications are subject to changes.
