3
INTRODUCTION
Thank you and congratulations on the purchase of your new Baker A / AX Band
Resaw. It has been designed to be durable, productive and easy to use. When properly
ran and maintained, it will provide you with many years of profitable operation.
For safety reasons, and for your own best use of the Baker A / AX Band Resaw, we
insist that you read this manual fully, and constantly review and refer back to it as
necessary.
No one should attempt to operate or perform maintenance on this equipment until they
have taken the time to read and understand the information contained in this manual.
** FAILING TO DO SO MAY RESULT IN SERIOUS INJURY **
Machine Purpose
Named for the shape of its frame, the Baker “A” and “AX” Band Resaw is great for all of
your resawing needs. You’ll cut at speeds not possible on many band resaws costing
much more. Resaw everything on it, or use it for short runs. Use it to cut boards or
cants, or reclaim slabs.
Machine Function
The Baker A Band Resaw is equipped with a 20 HP electric motor and accepts
material up to 7” x 7” (15 cm x 30 cm) and uses a 6” wide conveyor while the Baker AX
is equipped with a 30 HP electric motor and accepts material up to 7” x 12” (30 cm x 30
cm) with a 12” conveyor. Both models are capable of variable speeds from 0 – 120 feet
per minute as well as Baker’s exclusive guide system that includes guide plates and
guide roller.
Baker AX Model shown with:
(optional) Power Hold Down,
(optional) Power Hold Over
(optional) Return Conveyor.
