BALAY Washing Machine - Overview Programmes; Troubleshooting

7
Overview of programmes aRefer to the table of consumption values on page 8, and advice and warnings on page 6 .
Programmes °C max.
Type of laundry
Additional functions; Information
algod. (Cottons)
: - 90 °C
7 kg/ 4 kg*
hard-wearing fabrics, cottons or linen that c an be washed at 90°C
+ rápido
2*, + eco 1, men os w, extra 
+ prelav. (Prewash)
sintéticos (Easy-Care)
: - 60 °C
3.5 kg
easy-care cotton, linen, synthetic or blended fabrics
+ rápido
2, + eco 1, me nos w, extra 
+ prelav. (Prewash)
rápido mix (Quick Mix) : - 40 °C cotton or synthetic fabrics
+ rápido
2, + eco 1, me nos w, extra ;
different types of laundry can be washed to gether
r. oscura/r. escura (Dark Laundry)
: - 40 °C dark cotton and dark synth etic fabrics
+ rápido
2, + eco 1, me nos w, extra ;
reduced rinse and final spin cycle
camisas (Shirts/Business)
: - 60 °C
2 kg
non-iron shirts made of cotton, linen, synth etic fibres or blended fabrics
+ rápido
2, + eco 1, me nos w, extra ;
menos w: spin only, hang up dripping wet
delicados (Delicate/Silk)
: - 40 °C
for delicate fabrics, e.g., silk, satin, syntheti c fibres or blended fabrics (e.g. curtains)
+ rápido
2, + eco 1, me nos w, extra :
no spin between rinse cycles
ÿ lana/lã (Wool) : - 40 °C hand/machine washable wool
particularly delicate wash programme to avoid shrinkage of laundry; longer programme breaks (fabrics rest in th e detergent solution)
sup. rápido 15 min (Super Quick)
: - 40 °C
synthetic cotton, linen, synthetic fibres or blen ded fabrics
short programme of approx. 15 minutes, suitable for lightly soiled laundry
imperm. (Outdoor) : - 4 0 °C
all-weather, sports and outdoor fabrics including fabrics with weatherproof membrane
+ rápido
2, + eco 1, extr a ;
reduced final spin in intervals
lencería/lingerie (Lingery) : - 4 0 °C 1 kg lingery
+ rápido
2, + eco 1, me nos w, extra 
Additional programmes 2ü(Rinse)/c(Spin), 4ü(Empty), cdelicado (Gentle Spin)
* reduced load with additional function + rápido
2.

As a short programme rápido mix (Quick Mix) 40 °C with a maximum spin speed, is ideal. For programmes without prewash, add deter gent to compartment II. For prewash programmes, distribute the detergent between co mpartments I and II.
9010 / 9000554022
9000554022
3TS74120A /...
Balay Electrogeräte GmbH
CarläWery Str. 34
81739 Munich / Germany
8
Safety instructions
– Carefully read the instruction manual and the info rmation enclosed, and act accordingly.
– Keep the machine's documentation for future reference.
Risk of electric shock! – Never pull the cable to disconnect the mains plug!
– Never insert/disconnect the mains plug wi th damp hands.
Danger to life! For worn-out appliances:
– Disconnect the mains plug.
– Sever the mains cable and discard along w ith the plug.
– Destroy the lock on the washing mach ine door. This will prevent children from
locking themselves in and risking their li ves.
Danger of suffocation! – Keep packaging, film and packaging parts out of the reach of children.
Risk of poisoning! – Keep detergents and care products out of the reach of children.
Risk of explosion! – Items of laundry pretreated with cleaning ag ents containing solvents, e.g. stain
remover/cleaning solvent may lead to a n explosion after being loaded into the
washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury! – The washing machine do or may become very hot.
– Be careful when draining hot detergent soluti on.
– Do not climb onto the washing machi ne.
– Do not lean on the open washing machi ne door.
– Do not reach into the drum if it is still rota ting.
– Be careful when opening the detergent dr awer while the machine is in operation.
Consumption values de pending on model
Programme
Additional
function
Load Water***
Electricity***
Programme
duration
***
Water inlet temperature
cold 40 °C
algod. (Cottons) :](cold) 7 kg 60 l 0.24 kWh 0.24 kWh 145 min
algod. (Cottons)30 °C** 7 kg 59 l 0.37 kWh 0.37 kWh 145 min
algod. (Cottons)40 °C** 7 kg 59 l 0.98 kWh 0.64 kWh 155 min
algod. (Cottons)60 °C** 7 kg 59 l 1.15 kWh 0.88 kWh 165 min
algod. (Cottons)90 °C 7 kg 69 l 2.10 kWh 1.66 kWh 155 min
algod. (Cottons)60 °C
+ eco 1*
7 kg 42 l 1.05 kWh 0.85 kWh 180 min
sintéticos 40 °C** 3.5 kg 53 l 0.62 kWh 0.43 kWh 87 min
rápido mix 40 °C** 3.5 kg 47 l 0.54 kWh 0.41 kWh 60 min
delicados 30 °C 2 kg 34 l 0.19 kWh 0.19 kWh 41 min
delicados :](cold) 2 kg 35 l 0.05 kWh 0.05 kWh 41 min
lana/lã 30 °C 2 kg 39 l 0.17 kWh 0.17 kWh 40 min
lana/lã :](cold) 2 kg 3 9 l 0.0 3 kWh 0.03 kWh 40 min
* Programme setting for testing and ener gy labelling in accordance with EU directive 92/75/EEC.
** Programme s etting for testing in accordance with valid standard EN60456.
Note on comparative tests: For testing the test prog rammes, wash the specified load using the maximum spin speed.
As a short programme for coloureds, select the pr ogramme rápido mix (Quick Mix) 40 °C with the maximum spin
speed.
*** The values deviate from the indicated values depending on wa ter pressure, hardness, and inlet temperature, ambient tem-
perature, type, amount and soiling of the laun dry, detergent used, fluctuations in the power supply and selected additional
functions.
8
9
Care and cleaning
Before the first wash
Do not put laundry i n the machine! Turn on the tap. Put i nto compartment II:
– approx. 2 li tres of water
– detergent (mea sure according to the manufactu rer's instructions for lightly soiled l aundry and water hardness)
Turn the programme selector to sintéticos (Easy-C are)60 °C and press  (Start/Reload). At the end of the pr ogramme,
turn the programm e selector to o (stop).
Machine housing, control panel
– Wipe with a soft, damp cloth.
– Do not use any abrasive cloths, scourers or cleaning agents (stainless steel cleaners).
– Remove detergent and cleaning agent residue.
– Do not wash the machine with a jet of water!
Cleaning the deter gent drawer ...
... if it contains detergent or fabric softener residues.
1. P ull out, press insert down and remove d rawer completely.
2. To r emove the insert: press upwards from below with your finger.
3. For models with insert for liquid deterg ent:Slide the insert upwards and rem ove it from the back.
4. C lean the detergent dispenser tray an d inserts with water and a brush an d dry them.
5. At tach the insert and engage (conne ct the cylinder to the guide pin).
6. P ush in the detergent drawer.
Leave the detergent drawer open so that any residual water can evaporate.
Drum
Leave the washing machine door open so that the drum can dry out.
For rust stains, use chlorine-free cleaning agent, not steel wool.
Descaling En sure there is no laundry in the machine!
This will not be necessary if the correct dosage of detergent is used. If it is, descale the appliance according to the
manufacturer's instructions. Descaling products can be acquired on the website or from customer services aInstallation
instructions.
Emergency release (e.g. in the event of a power cut)
The programme continues to run when the power has been restored. However, if the laundry has to be removed, the
washing machine door can be opened as follows:
Risk of scalding!
The detergent solution and laundry may be hot. Let it cool.
Do not reach into the drum if it is still rotating.
Do not open the washing machine door if water can be seen through the glass.
1. Turn the programme selector to o (stop) and disconnect the mains plug.
2. D rain the detergent solution apage 10.
3. P ull the emergency release downwards with a tool and release.
The washing mac hine door can then be opened.
Information on the display panel depending on model
,flashes
Close the washing machine door properly; laundry may be caught.
§: ³Å,
§
: É
Turn on the tap fully, supply hose kinked or trapped;
Clean the filter apage 10, water pressure too low.
§: ³µDetergent solution pump blocked; Clean the detergent solution pump apage 10.
Drainage hose / waste pipe blocked; Clean the drainage hose at the siphon apage 10.
§: ´
Water in the base tub, appliance leaking. Call customer services!
©: ³¯
Not a fault. Entry of unused hot water. Check hot water tap.
#Childproof lock activated: to deactivate a page 5.
– Risk of electr ic shock! Disconnect the mains plug.
– Risk of explos ion! Do not use solvents.
9
10
Maintenance
Detergent solution pump
Turn the programme selector to o (stop) and d isconnect
the mains plug.
1. Usin g a screwdriver or the insert for liquid detergent
(depending on model), open and remove the service flap.
2. Remove t he folding gutter and place a large enough container underneath.
3. For models with a drainage hose: Remove the drainage hose from the retainer and pull it
from the housing.
Remove the sealing cap, allow the detergent solution to flow out into the container. Replace
the sealing cap and place the drainage hose in the retainer.
3* For models without a drainage hose: Carefully unscrew the pump cover 180° or until the
detergent solution begins to flow out on the folding gutter. When the container is full, close
the pump cover and empty the container. Rep eat the above steps until all the detergent
solution has completely drained out.
4. Caref ully unscrew the pump cover (there may be residual water).
5. Cle an the interior, pump cover thread and pump housing (the impeller in the detergent
solution pump must rotate).
6. Rep lace the pump cover and screw it tightly.
7. Retur n the drainage hose (depending on model) and the folding gutter to their start position.
8. Plac e the service flap back on and close.
To prevent unused detergent from flowing str aight into the drain during the next wash:
Pour 2 litres of water into compartment II and then s tart the 4
ü(Empty) programme.
Drainage hos e at the siphon
Turn the programme selector to o (stop) and d isconnect the mains plug.
1. Loo sen the hose clamp, carefully remove the drainage hose (residual water).
2. Cle an the drainage hose and siphon connecting piece.
3. Rea ttach the drainage hose and secure the connection with the hose clamp.
Filter in the water supply
Risk of electric shock!
Do not immerse the Aqua-Stop safety device in wa ter (contains an electric valve).
Reduce the water pressure in the supply hose:
1. Turn o ff the tap.
2. Select an y programme (except 2
ü(Rinse)/c(Spin) // 4(Empty)).
3. Cho ose  (Start/Reload). Let the programme run for approximately 40 seconds.
4. Turn th e programme selector to o (stop). Disconnect the mains plug.
Clean the filter:
5. Disconne ct the hose from the tap.
Clean the filter using a small brush.
and/or for Standard and Aqua-Secure models:
Remove the hose on the rear of the applianc e.
Remove the filter with pliers and clean.
6. Con nect the hose and check for leaks.
– R isk of burning!
Allow the detergent solution to cool.
– T urn off the tap.
11
What to do if...
ʑ
Water is leaking out – Attach/replace the drainage hose correctly .
– Tighten the screw connection of the supply hose.
ʑ
No water supply.
Detergent not dispensed.
–  (Start/Reload) not selected?
– Tap not turned on?
– Filter blocked? Clean the filter a page 10.
– Supply hose kinked or trapped?
ʑ
The appliance door will not
open.
– Safety function active. Programme stopped? apage 4.
–  (without final spin) selected? apa ge 3, 4.
– Can be opened by emergency release only? a page 9.
– Door locked after the washing machine is s witched off: Switch on the washing
machine and wait for 5 seconds.
ʑ
The selected programme does
not start.
–  (Start/Reload)or b (h) (Ready in) time selected?
– Washing machine door closed?
– Childproof lock active? Deactivate apage 5.
ʑ
Detergent solution is not
drained.
–  (without final spin) selected? apa ge 3, 4.
– Clean the detergent solution pump apage 10 .
– Clean the waste pipe and/or drainage hose.
ʑ
No water can be seen in the
drum.
– Not a fault. Water remains inside below th e visible area.
ʑ
Spin result not satisfactory.
Laundry wet/too damp.
– Not a fault. Spin control system has stopped the spin cycle. Uneven distribution of
laundry.
Distribute large and small items of laundry evenly in the drum.
– menos S(Reduced Ironing) selected? a page 5.
– Selected speed too low? apage 5.
ʑ
Programme duration changes
suddenly during operation.
– Not a fault. The program time can vary according to the distribution of laundry, with
it therefore being possible for the display panel to show adjustments in the
duration.
ʑ
Spin cycle performed several
times.
– Not a fault. The balance control system has detected an imbalance and is
attempting to redress this by repeating the spin.
ʑ
Residual water in the
compartment for care products.
– Not a fault: the action of the care product is not affected.
– Clean the compartment if necessary apage 9 .
ʑ
Odour formation in the washing
machine.
– Run programme algod. (Cottons)90 °C without laundry. Use standard detergent.
ʑ
Status display 1 flashing.
Appliance has detected a
detergent overload.
– Too much detergent used?
If foam is escaping from the detergent drawer: mix 1 tablespoon of fabric softener
with ½ litre of water and pour into compartment II (not with outdoor or down
fabrics).
– Reduce the detergent dosage for the next wash cyc le.
ʑ
Intense noise formation,
vibrations and "wandering"
during the spin cycle.
– Are the appliance feet fixed?
Secure the appliance feet aInsta llation instructions.
– Transportation safety devices removed?
Remove transportation safety devices aInstallation instructions.
ʑ
Display panel/indicator lamps
remain turned off while the
machine is working.
– Energy-saving mode apage 5.
– Power cut?
– Fuses triggered? Reset/change the fuse.
– If the fault occurs repeatedly, call customer services.
ʑ
Programme sequence longer
than usual.
– Not a fault. Unbalanced load detection syst em adjusts imbalance by repeatedly
distributing the laundry.
– Not a fault: foam detection system active; adds an additional rinse cycle.
ʑ
Detergent residues on the
laundry.
– Occasionally, phosphate-free detergents contai n water-insoluble residues.
– Select 2
ü(Rinse)/c(Spin) or brush out the laundry after washing.
If you cannot correct a fault yourself or if a repair is necessary:
– Turn the programme selector to o (stop) a nd remove the mains plug from the socket.
– Turn off the water supply and call customer serv ices aInstallation instructions.
Instructions for use
en
Washing
Machine
Observe the safety instructions on
page 8!
Read these instructions and the separate
installation instructions before operating
the washing machine.
