Baldwin Boxall VIGIL ECLIPSE - Page 9

- 9 -
Issue 6
TERMINATIONS AND CONNECTIONS Continued
Termination
Board
Function Description
AMP1 O/P 100V line loudspeaker output 1
AMP1 0V Earth for BEL1
AMP1 O/P 100V line loudspeaker output 1
AMP2 O/P 100V line loudspeaker output 2
AMP2 0V Earth for BEL1
AMP2 O/P 100V line loudspeaker output 2
AMP3 O/P 100V line loudspeaker output 3
AMP3 0V Earth for BEL1
AMP3 O/P 100V line loudspeaker output 3
AMP4 O/P 100V line loudspeaker output 4
AMP4 0V Earth for BEL1
AMP4 O/P 100V line loudspeaker output 4
AMP5 O/P 100V line loudspeaker output 5
AMP5 0V Earth for BEL1
AMP5 O/P 100V line loudspeaker output 5
AMP6 O/P 100V line loudspeaker output 6
AMP6 0V Earth for BEL1
AMP6 O/P 100V line loudspeaker output 6
AMP7 O/P 100V line loudspeaker output 7
AMP7 0V Earth for BEL1
AMP7 O/P 100V line loudspeaker output 7
AMP8 O/P 100V line loudspeaker output 8
AMP8 0V Earth for BEL1
AMP8 O/P 100V line loudspeaker output 8
L Live Mains Input )
E Earth Mains Input ) Max 1400 VA, fuse at 13A
N Neutral Mains Input )
The above termination list should be used in conjunction with the relevant wiring diagrams
found in their respective Operating Instruction Manual.
Low Volta
g
e Directive
73/23/EEC as amended
by 93/68/EEC
EMC Directive
89/336/EEC as amended
by 92/31/EEC and 93/68/EEC
Applies onl
y
when the items
are correctl
y
fitted and operated
in or with products of our
manufacture and are installed
in a recommended enclosure
