1. PART NAMES AND FUNCTIONS
1
Air intake grille
INDOOR UNIT
Air outlet
Remote
control
unit
Drain hose
Refrigerant tubes
OUTDOOR UNIT
Air outlet
INDOOR UNIT
OPERATING lamp
TIMER lamp
POWER lamp
POWER
TIMER
OPERATING
HI POWER
HIGH
POWER
lamp
REMOTE CONTROL receiver ON/OFF button
ON/OFF
KFR-3301GWE KFR-3201GWE KFR-2501GWE KFR-33GWE
KF(R)-25GWE KF-34GWE
