Balluff BTL PF 400 C15A Series User Manual

www.balluff.com 19english
The specifications are typical values for
BTL PF _ 400- _ _ _ _ -C15A _ _ _ _ - _ _ _ _ _ _ with 24VDC
and at room temperature and with a measuring length of
500 mm in conjunction with the magnet BTL5-P-3800-2,
BTL5-P-4500-1, BTL5-P-5500-2, BTL6-A-3800-2,
BTL6-A-3801-2, BTL5-F-28141-S or BTL5-T-28141-S.
The product is immediately ready for operation, full
accuracy is achieved after the warm-up phase.
Further data can be found at www.balluff.com
on the product page.
9.1 Ambient conditions
Ambient temperature −25…+85°C
Storage temperature −40…+100°C
Relative humidity ≤ 90%, non-
condensing
Typ. temperature coefficient
1)
≤ 30 ppm/K
Shock rating as per
EN 60068-2-27
2), 3)
100g/6ms
Continuous shock per
EN 60068-2-27
2), 3)
50 g/2ms
Vibration per EN 60068-2-6
2), 3)
12g, 10
…2000Hz
Protection per IEC60529 (when
threaded together)
IP67
9.2 Detection range/Measuring range
Measuring length 25...4000mm
Analog resolution
…-C15AA/-C15A1… 183μV / ≥4μm
…-C15AE/C/-C15A5/3… 351nA / ≥4μm
Repeat accuracy
Measuring length ≤ 500mm ≤±10µm
Measuring length > 500mm ≤±0.002%FS
Length-dependent measuring
frequency
…-C15A___0-…
Measuring length ≤ 1270mm 1000Hz
Measuring length > 1270 to
≤2650mm
500Hz
Measuring length > 2650mm 250Hz
…-C15A__CA-… (High update rate)
Measuring length ≤ 240mm 4000Hz
Measuring length >240 to
≤590mm
2000Hz
Linearity deviation
4)
with measuring length ≤500mm ≤±60µm
with measuring length > 500 to
≤4000mm
≤±0.012%FS
Detectable speed ≤ 10m/s
9.3 Electrical data
Operating voltageU
b
10…30VDC
Current draw (at24VDC)
…-C15AA__0-…/…-C15A1__0-… ≤ 80mA
…-C15AE/C__0-…/
…-C15A5/3__0-…
≤ 110mA
…-C15AA__A-…/…-C15A1__A-… ≤ 90mA
…-C15AE__A-…/…-C15A5__A-… ≤ 120mA
Power consumption
…-C15AA__0-…/…-C15A1__0-… ≤2.0W
…-C15AE/E__0-…/
…-C15A5/3__0-…
≤2.7W
…-C15AA__A-…/…-C15A1__A-… ≤ 2.2W
…-C15AE__A-…/…-C15A5__A-… ≤ 2.9W
Overvoltage protection U
b
up to 36VDC
Voltage-proof up to (GND – Housing) 500VDC
…-C15AA/C15A1…
Output current ≤ 5mA
…-C15AE/C/C15A5/3…
Load resistance R
Lc
≤ 500ohm
9.4 Electrical connection
Short circuit protection Signal output to
GND and
30VDC
Protected against polarity reversal
5)
U
b
up to 30VDC
1)
Measuring length 500mm, magnet in the middle of the measuring range
2)
Individual specifications as per Balluff standard
3)
Resonant frequencies excluded
4)
Configuration for one magnet
5)
A prerequisite is that no current can flow between GND and 0V in the
event of polarity reversal.
9
Technical data
BTL PF _ 400- _ _ _ _ -C15A _ _ _ _ - _ _ _ _ _ _
Magnetostrictive Linear Position Sensor – Profile Style

Balluff BTL PF 400 C15A Series Specifications
