Balluff BTL PF 400 C15A Series User Manual

www.balluff.com 23english
11
Type code
BTL PF1400-0500-C15AA1C0-000S15
Construction:
P = Profile
Housing geometry:
F = Profile housing, flat 35×20.8mm
Installation:
0 = without mounting clamps
1 = with mounting clamps (BTL6-A-MF07-A-PF/M5)
Mechanical zero point:
4 = Zero point at 67mm
Measuring length (4 digits):
0500 = metric specification in mm; measuring length 500 mm (0025...4000)
Interface:
A = Analog
Output1:
A = Voltage output 0...10V
1 = Voltage output 10...0V
E = Current output 4...20mA
5 = Current output 20...4mA
C = Current output 0...20 mA
3 = Current output 20...0mA
Output2:
A = Voltage output 0...10V
1 = Voltage output 10...0V
E = Current output 4...20mA
5 = Current output 20...4mA
C = Current output 0...20 mA
3 = Current output 20...0mA
0 = no signal
Output configuration:
A = Output 1: Position of magnet 1, configurable with BET
B = Output 1: Position of magnet 1;
Output 2: Position of magnet 2; FMM; configurable with BET
C = Outputs 1 and 2: Position of magnet 1, configurable with BET
Option:
0 = Default configuration
A = High-update-rate configuration
Electrical connection:
000S15 = 8-pin, M12 plug
000S32 = 8-pin, M16 plug per IEC130-9
000S35 = 6-pin, M16 plug per IEC130-9
CA5000 = Cable, 5m (PUR)
954874_AA ∙ EN ∙ E22 ; Subject to modification.
BTL PF _ 400- _ _ _ _ -C15A _ _ _ _ - _ _ _ _ _ _
Magnetostrictive Linear Position Sensor – Profile Style
