OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
28
Error indicator readout
If the LED diagnostic readout displays an error code, such as LL, push in and turn
the red Emergency Stop button to reset the system.
List of Fault Codes
Display
Description
Lift Reaction
01
System initialization Fault
Disables All Motion
02
System communication Fault
Disables All Motion
03
Invalid option setting Fault
Disables All Motion
12
Chassis Up/Down Switch ON at Power-up Fault
Disable Chassis Control
18
Pothole Guard Fault
Disable Lifting and Driving
31
Pressure Sensor Fault
Disables All Motion
32
Angle Sensor Fault
Disables All Motion
34
Reserved
42
Platform Left Turn Switch ON at power-up Message
Diagnostic Message Only
43
Platform Right Turn Switch ON at power-up Message
Diagnostic Message Only
46
Platform Joystick Enable Switch ON at power-up Fault
Disable Platform Control
47
Platform Joystick not in neutral at power-up Message
Diagnostic Message Only
52
Drive Forward Coil Fault
Disable Lifting and Driving
53
Drive Reverse Coil Fault
Disable Lifting and Driving
54
Lift Up Coil Fault
Disable Lifting and Driving
55
Lift Down Coil Fault
Disable Lifting and Driving
56
Right Turn Coil Fault
Disable Lifting and Driving
57
Left Turn Coil Fault
Disable Lifting and Driving
58
General Brake Coil Fault
Disable Lifting and Driving
59
Parallel Coil Fault
Disable Lifting and Driving
61
Motor Controller Current Sensor Fault
Controller Dependent
62
Motor Controller Hardware Failsafe Fault
Controller Dependent
