Balt 34459 - Door and Top Panel Integration

4
Be sure that arrow on
top of Camlock (F)
aligns with centerline of
Edge Drilled hole.
Phillips
Screwdriver
Centerline of
Edge Drilled
hole.
Arrow
Attach 1 each Door
Magnet (K) to the Top Panel
(P-4) and secure using 2
Wood Screws (A2) as
shown in illustration # 4.
J
E
P-4
C
10.
A2
7.
9.
Place the Door (P-6) with the Screw Holes facing up and
install 1 Lock (G) into the large hole using 4 Wood Screws
(A). Press Lock Ring on from front side
as shown in illustration # 3.
Attach Door Knob (J) to Door (P-6) using
1 each (A1) screw.
Locate 2 each Spring Buttons (E) in the top
and bottom of door (P-6).
6.
Illustration # 4
Place the Top Panel (P-4) with the Holes
facing up and install 4 each Cam Locks
(C) into the large holes as shown in
illustration # 4.
Illustration # 3
P-6
A
E
A1
G
8.
Lock Ring
K
