Steam pressure check
Setpoint 1 bar 10 bar 16 bar 25 bar 40 bar
Up to 100 kPa 1000 kPa 1600 kPa 2.5 MPa 4.0 MPa
Parameter Factory
setting
Suggested setting
Pb. 50 10% of the setpoint value
Int 200 160 200
Der 50 40 50
dp 0 1
HCFG rtd I
SSC 0 0
FSC 0 Probe full scale value
SENS PT10 4.20
SPLL -1999 0
SPHL +9999 1.0 10.0 16.0 25.0 40.0
dif bAlt bAlt
O1F 1.rEG 1.rEG
O2F 2.rEG 2.rEG
O3F AL.no AL.NC
OAL1 Out2 Out2
AL1t HI.dE HI.dE
AL1 --- -15
OAL2 Out3 Out3
AL2t HIAb Hide
AL2 90 5
SStE YES NO
SstL 30 Limit of Initial standby disabling
SSt InF Initial standby
AUTO 7 Starting by means of key "U"
Add 1 1
FIL 0,2 0,5
REGULATOR CONFIGURATION TABLE MOD ASCON LC3
Temperature check
Setpoint Up to 100°C From 100°C to
500°C
From 500°C to
1100°C
Temperature probe Pt 1000 Pt 1000 Thermocouple “K”
Parameter Factory
setting
Suggested setting
Pb.1 50 15% 10 -20 (10% of Sp1) 20% of SP
Int 200 350 250 200
Der 50 OFF OFF OFF
dp 0 1 0
tcor 60 time required by the servomotor to go from min to max power
HCFG rtd rtd tc
SENS PT10 PT10 CrAl
SPLL - 1999 Minimum boiler operating temperature
SPHL + 9999 Maximum boiler operating temperature
dif bAlt bAlt
O1F 1.rEG 1.rEG
O2F 2.rEG 2.rEG
O3F AL.no AL.NC
OAL1 Out2 Out2
AL1t HI.dE HI.dE
AL1 --- -15
OAL2 Out3 Out3
AL2t HIAb Hide
AL2 90 5
SStE YES NO
SstL 30 Limit of Initial standby disabling
SSt InF Initial standby
AUTO 7 Starting by means of key "U"
Add 1 1
FIL 0,2 1,5
