SPARE PART LIST FOR
MOTOREDUCER ROY 9
1. PLASTIC COVER WITH SCREWS
2. COMPLETE MOTOR CAP
3. STATOR
4. COMPLETE ALUMINIUM BODY
5. ELICOIDAL WHEEL
6. COMPLETE SIDECAP
7. COMPLETE MOTOR SHAFT WITH CLUTCH
8. COMPLETE FINAL SHAFT
9. PINION.
10. COMPLETE CLOSING LIMIT SWITCH (YELLOW)
11. COMPLETE OPENING LIMIT SWITCH (GREEN)
12. FIXING PLATE WITH SCREWS AND BOLTS
12
78
456
123
91011
14
