Banana Pi BPI-M2+ - Page 13

CON2-P31 PA8-EINT8 PA8-EINT8
CON2-P32 PL2-S-EINT2 PL2-S-EINT2
CON2-P33 PA9-EINT9 PA9-EINT9
CON2-P34 GND
CON2-P35 PA10-EINT10 PA10-EINT10
CON2-P36 PL4-S-EINT4 PL4-S-EINT4
CON2-P37 PA17-EINT17 PA17-EINT17 SPDIF-OUT
CON2-P38 PA21-EINT21 PA21-EINT21
CON2-P39 GND
CON2-P40 PA20-EINT20 PA20-EINT20
CSICameraConnectorspecification:
TheCSICameraConnectorisa24-pinFPCconnectorwhichcanconnectexternalcamera
modulewithpropersignalpinmappings.ThepindefinitionsoftheCSIinterfaceareshown
asbelow.ThisismarkedontheBananaPiboardas“CSI″.
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
13BPI-M2+Pindefine
