Banana Pi BPI-M2+ - BPI-M2+ Pin define

CPU H3Quad-coreCortex-A7H.265/HEVC4K
GPU Mali400MP2GPU@600MHz,SupportsOpenGLES2.0
Memory
(SDRAM)
1GBDDR3(sharedwithGPU)
Onboard
Storage
TFcard(Max.64GB)/MMCcardslot,upto2Ton2.5SATAdisk,8GB
EMMCFlash
Onboard
Network
10/100/1000MEthernetRJ45
Onboard
WIFI
SDIOAP6212（optionAP6181、AP6335）
Video
Input
ACSIinputconnectorCamera:1Supports8-bitYUV422CMOSsensor
interface,2SupportsCCIR656protocolforNTSCandPAL,3Supports
SMpixelcamerasensor,4Supportsvideocapturesolutionupto
1080p@30fps
Video
Outputs
SupportsHDMIoutputwithHDCP,SupportsHDMICEC,SupportsHDMI
30function,IntegratedCVBS,SupportssimultaneousoutputofHDMIand
CVBS
Audio
Output
HDMI
Power
Source
DCinputcansupplypower,butUSBOTGinputdon’tsupplypower
USB2.0
Ports
twoUSB2.0HOST,oneUSB2.0OTG
Buttons PowerButton,RecoveryButton,UbootButton
Low-level
peripherals
40PinsHeader,compatiblewithRaspberryPiB+
uart
GPIO(1x3)
pin
UART,ground
LED Powerled&Statusled
IR IRinputonboard
Supported
OS
Android,Ubuntu,Debian,RasberryPiImage
Product
size
65mm×65mm
Weight 48g
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
9BPI-M2+hardwarespec
