2 PRODUCT OVERVIEW
2.1 FUNCTIONAL PURPOSE OF THE DEVICE
The system for monitoring pH and ORP consists of two main parts:
• the meter/regulator described in this instruction manual;
• a probe/measuring electrode.
The instrument contains the electronic circuitry and firmware to perform the following
functions:
• display the measurement values of pH or ORP of aqueous solutions, with an appro-
priate sensor connected;
• view of the temperature values, if a temperature sensor Pt100 or Pt1000 is connect-
ed;
• perform the automatic or manual temperature compensation of pH measurements;
• automatic control of pH or ORP, if the output relays are connected to appropriate
metering pumps or solenoid valves;
• provide an alarm if the measuring exceeds the minimum or maximum limits estab-
lished of if relays remain activated for more time than established;
• provide two output signals for recording or the acquisition of pH or ORP measuring
values;
• acquire external contacts to activate the alarm or keep the instrument in hold;
• enable automatic or manual cleaning cycles when connected to appropriate devic-
es.
Pumps or valves can be activated directly by the instrument or by external control
switches if their power load is not compatible with the instrument's relays.
2.2 ACCESSORIES
Sensors and accessories for different applications are available, to be ordered separate-
ly.
Our web site www.bc-electronics.it
contains accessories, upgrades and detailed speci-
fications of each product.
Our staff is always available to help costumers select the most appropriate and suitable
solution for their specific needs.
