B&G Network Network System - Installation Data

NETWORK COMPASS USER MANUAL
INSTALLATION DATA
82.0mm
82.0mm
Mounting bracket
Gasket
Bulkhead
Fit the gasket around
the mounting bracket
Rubber Gasket
Gasket
Display Unit
Sun-cover
Self-tapping screws
Mounting bracket
70.0mm hole
25.0mm 65.0mm
110.0mm
110.0mm
Network COMPASS
LIGHTS
ENTER
SETUPTIMERMODE LOCK
Network connector Network & Power connector
Locking stud fixing
Fluxgate
Remote button
22
