Bandit
33
Copyright 6/18
MODELS 60FM / 72FM
LOCATION PART NUMBER DESCRIPTION
FORESTRY MULCHER COMPONENTS
*-* Cutter head motor needs to be ordered by the Forestry Mulcher serial number,
see page 35 for images.
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
1. a. 401-2000-12 Push Bar Assembly - 60FM
b. 401-2000-29 Push Bar Assembly - 72FM
2. 401-2000-13 Push Bar Arm
3. 401-2000-08 Access Door
4. 401-3001-09 Center Access Door
5. 900-3982-73 Hydraulic Panel Gauge
6. 401-2000-57 Hydraulic Panel Gauge Holder
7. 401-3000-82 Right Side Access Door
8. 900-3958-80 Cylinder for Optional Gate
9. 996-3007-06 Beltshield Access Cover
10. 987-3014-72 Bandit Name Plate
11. 401-3002-65 Tach Inspection Cover
12. 963-3003-19 Beltshield Cover
13. a. 401-1000-03 Overhung Load Adapter Assembly
b. 900-1921-55 Overhung Load Adapter Bearing
c. 401-2000-18 Splined Shaft Only
d. 401-3000-79 Locking Pin Only
e. 401-2000-17 Overhung Load Adapter Housing Only
f. 401-3002-74 Overhung Load Adapter Bearing Seat Ring
14. *-* Cutter Head Motor
15. 900-3966-56 Cutter Head Manifold
16. 900-4921-48 Spring Loaded Hose Holder
17. 401-3002-46 Spring Loaded Hose Holder Mount Tab
18. 401-3000-89 Plastic Hose Holder
19. 401-3000-88 Hose Holder Ring
20. 401-3000-70 Deection Chain
21. 401-3002-64 Non Drive Beltshield
22. a. 963-2001-13 Mulcher Foot - Right Side (60FM Start S/N 1036) - (72FM Start 9/15 approx.)
b. 401-2000-06 Mulcher Foot - Right Side (60FM Pre S/N 1036) - (72FM Pre 9/15 approx.)
23. 963-3003-15 Beltshield Filler - Right Side
24. 963-3003-91 Bearing Cover
25. 963-2001-14 Mulcher Foot Assembly - Left Side
26. 963-2000-78 Beltshield Filler - Left Side
27. 900-1911-39 Cutter Head Sheave
28. 900-1911-06 Cutter Head Bushing
29. 900-1910-92 Forestry Mulcher Belt (Poly Chain)
30. 900-1906-01 Hydraulic Motor Bushing
31. 900-1910-93 Hydraulic Motor Sheave
32. 401-2000-19 Adjustable Mount for Overhung Load Adapter
33. 963-3005-54 Sheave Spacer
34. 900-1918-96 Cutter Head Bearing - Right Side
35. 401-3001-22 Spacer Ring
36. 401-2000-23 Bearing Mount Assembly - Right Side
37. 900-1918-21 Taper Lock Bushing
38. a. 401-1000-02 Cutter Head Assembly - 60FM
b. 401-1000-05 Cutter Head Assembly - 72FM
c. 900-4904-64 3/4”-10NC x 4” Hex Head Bolt - Tooth
d. 900-4918-57 3/4” NordLock Washer - Tooth
e. 963-3003-03 Taper Lock Bushing Cover (2 Per Head)
39. a. 401-3000-63 Cutter Head Shaft - 60FM
b. 401-3001-34 Cutter Head Shaft - 72FM
40. 401-2000-24 Bearing Mount Assembly - Left Side
41. 900-1918-99 Cutter Head Bearing - Left Side
42. a. 401-2000-11 Optional Gate Assembly - 60FM
b. 401-2000-32 Optional Gate Assembly - 72FM
43. a. 401-3000-53 Gate Hinge Pin - 60FM (Not Shown)
b. 963-3004-01 Gate Hinge Pin - 72FM (Not Shown)
44. 900-9910-28 Manual Holder
