PAGE 8 OF 12
4.3 Replacing rubber baffels
a. Using the disassembly tool, remove the cover (right-hand
thread) from the suppressor. In order to do this, place the
bulged end of the disassembly tool in the cover and turn it
counterclockwise.
b. Push the baffels out.
c. Using the ejection tool (not included in the scope of deliv-
ery), push the residue out of the pistol in the direction of
firing.
Mini-JET (1 spacer, 2 bafes)
JET (3 spacers, 4 bafes)
