5
B
Fixing the receiver to the
wall
1 Use the wall bracket as a
template, mark and drill the
holes in the wall.
2 Use the two screws and wall
plugs supplied (A), fasten the
wall bracket.
3 When you have mounted the
receiver cable (see page 6)
place the receiver on the wall
bracket and then secure it
with the tiny screw (B).
4 Fasten the cable to the wall
and run it to the amplifier
box.
Fixing the amplifier box to
the wall
The rear part of the amplifier
box has been furnished with
two ‘keyholes’ (C), which may
be used to fasten the box to
e.g. a wall.
Note! Light partition walls are
often constructed of gypsum
panels – known as drywall or
wall board – secured to vertical
studs. Gypsum is not a satisfac-
tory material to support the
weight of the amplifier box!
If you wish to fix the BeoLink
Passive amplifier box on such a
wall, be sure to use the correct
size and type of screws and
plugs.
A
A
CC
