Bang & Olufsen BeoLink User Manual

MASTER LINK
Another type of invisible installation is shown below. This installation can
be made for example in apartments with no access to the attic or
basement.
24
In this example the following has been used:
1. 4 x Master Link cable with two plugs
2. Master Link cable without plugs
3. 4 x Master Link wall socket
4. 1 x datalink cable (included with BeoLink Video)
5. 1 x BeoLink Video
Aerial installation
Aerial installation with built-in splitter.
Aerial installation with external splitter.
