2.2 Fault flow chart
Placement of measuringpoints
A. F220, PCB4
B. W20 (1P7 - 5P119)
C. FP41, 42, 43, 44, PCB4
D. 4P116, PCB4
E. 8P1, PCB8
F. W7 (8P1 - LCD)
G. W5 (5P140 - LCD)
H. 8P2, PCB8
I. W6 (8P2 - 4P116)
J. P167, PCB4
K. Label with Adjustment values
L. P9, PCB1
M. W15 (1P9 - 58P141)
N. 74P103, PCB74
O. 74P114, PCB74
LCD
