Bang & Olufsen BeoVision 7 MK II User Manual

2.4 Fault flow chart
Fault symptom:
- No start up
- Standby light = red
Possible cause:
- PIN-code locked
- Option 0
- Status display defect
- Mains chassis defect
- Beo4 / Remote control defect
Press TV on the Beo4
- - - - - - - -
OSD displays “WAIT”
- - - - - - - -
PIN-code locked
Set the television in
OPTION 1
- - - - - - - -
Does St-by. led blink
one time?
- - - - - - - -
Option 0 = Status
display is disabled
Ensure that the
television is in
Standby mode
- - - - - - - -
The television has
been locked for 3
hours since last PIN-
code was entered
Press TV on the Beo4
- - - - - - - -
TV OK?
- - - - - - - -
Status display is
enabled
Replace Main chassis
(Module 999)
- - - - - - - -
Main chassis defect
Check the Beo4 on
another product
- - - - - - - -
Other product
responds correctly
- - - - - - - -
Beo4
Replace the batteries
in the Beo4
- - - - - - - -
TV OK?
- - - - - - - -
Beo4
Beo4 defect
Try a new Beo4
- - - - - - - -
TV OK?
- - - - - - - -
Beo4
Fault may be located
in any of the PCBs
The old Beo4 is defect
Replace Main chassis
(module 999)
Replace
Status display
(PCB58)
Action
- - - - - - - -
Confirm
- - - - - - - -
Checked
No
Yes
