A. Electric Scooter Assembly
1. Using the proper screwdriver or bit type
and size, carefully loosen each screw that is
securing the motor cover, .
2. Remove each screw and set aside for reuse.
3. Gently lift and remove the collar from the
motor spindle.
Attention:
Removing the screws in a diagonal pattern
is recommended to avoid stripping and
damaging the screws and the threads.
Attention:
Exercise caution with the power cable
when removing set collar.
Motor Disassembly
