ECO 60 / 70 / 90 / 100
• Check the operation and setting of the ue gas ap (ECO 60).
• If necessary, the ue gas ap pin can be adjusted (ECO 60).
Flue gas ap pin
Flue gas ap
Door open Pin comes forwards Flue gas ap open
Door closed Pin is pressed in by the door Flue gas ap closed
