This will not only avoid poor combustion, but will also prevent ue gases
being sucked from the appliance into the room.
Should creating an extra ventilation opening prove insufcient, it is then
necessary to t a ue gas fan.
• Combustion air directly from outside:
The appliance now has a completely closed combustion syst
em
, which
allows it to operate independently of the surrounding air in the room where
the appliance is located.
3.4. FITTING THE STOVE
3.4.1. Connecting the smoke outlet
ECO 60:
The appliance can make use of either a top or rear connection Ø150 mm
(Ø150 mm external) for the ue (chimney).
The appliance is supplied with the ue gas exhaust ue connection and cover
plate that was stated with the order.
Assembling of the smoke outlet ECO 60 top connection:
- Install the cast-iron ue gas exhaust ue connection ring to the top of the
appliance.
Attention ! Ensure that the sealing cord
ts properly all round.
