- Place the cover plate on top of the appliance.
ECO 70/90/100:
The appliance has only a top connection Ø150 mm (Ø150 mm external) for the
ue (chimney).
See ECO 60 for the sequence for installing the ue gas exhaust.
General:
The smoke outlet connection is intended for steel stovepipes, double/single-
skinned stainless steel (insulated) ues or double/single-skinned exible
stainless steel ues.
Situate the appliance in such a way that the ue gas outlet is precisely in line
under the chimney connection (niche pipe) in the ceiling (top connection) or with
the chimney connection (niche pipe) in the wall (rear connection).
3.4.2. Exchanging smoke gas exhaust top and rear connection ECO 60
• In order to be able to exchange the smoke outlet top- and rear connection,
rst remove the ue gas ap and the brake plate rst.
See chapter 11 for the disassembly sequence of the ue gas ap and the
brake plate: “Sequence for replacing the interior of the appliance ECO 60”.
