3.4.4 Connecting to the chimney
Ceiling connection:
Insert a pipe into the sliding sleeve (niche pipe) to the ceiling as deep as
possible. Position a chimney pipe on the top plate and mark off where the top
pipe should be shortened.
Shorten the top pipe and insert it, once more, as deep as possible into the
sliding sleeve in the ceiling. Position the lower pipe over the sealing washer.
Now pull the top pipe down and over the bottom pipe.
Wall connection (ECO 60):
Determine the length of pipe required and push this as far as possible into the
sliding sleeve before the appliance is placed.
Once the appliance is placed, you can pull the pipe from the sliding sleeve and
slide it over the connection ring on the appliance.
Any seams in the ue gas outlet (pipes) joints should be
sealed with a heat-resistant kit that remains elastic or
with a glass-bre cord.
3.4.5 Connecting direct air supply connection
If you wish to use the appliance independently of the surrounding air in the
space where the appliance is located, then you should make a direct
combustion air intake from outside to the appliance.
