58
ECO 60 / 70 / 90 / 100
When ordering, please give the serial number.
124 3
5
10 9 6
7
8
11
1213
14
Item no Description replacement parts ECO 90 Number
1 Body 1
2 Smoke connection (top) 1
3 Panel rear, top (vermiculite plate) 1
4 Panel side, right (vermiculite plate) 1
5 Retardant plate (brake plate) under (vermiculite plate) 1
6 Panel bottom, rear (vermiculite plate) 1
7 Grate 1
8 Ashtray 1
9 Panel rear, under (vermiculite plate) 1
10 Retardant plate (brake plate) top (vermiculite plate) 1
11 Panel bottom, front (vermiculite plate) 1
12 Panel side, left (vermiculite platet) 1
13 Door 1
14 Glass 1
11.3 ECO 90
