Barco E2 Safety Guide

1. Safety
1.4 Plug types E2
ACPowercordwithNEMA5/15plugupto13A
NEMA 5/15
E
L
N
The wires of the power cord are colored in accordance with the following code:
Green or yellow + green: Earth (Ground)
Blue or white: Neutral
Brownorblack: Line(Live)
PowercordwithGB2099plugupto10A
The wires of the mains lead are colored in accordance with the following code:
Green + yellow: Earth (Ground)
Blue: Neutral
Brown: Line (Live)
AC Power cord (mains lead) with CEE 7 plug up to 10 A
CEE 7
E
N
L
The wires of the mains lead are colored in accordance with the following code:
Green + yellow: Earth (Ground)
Blue: Neutral
Brown: Line (Live)
R5905947 E2 09/03/2018
5

Barco E2 Specifications

General

4K Support	Yes
Genlock	Yes
HDCP Support	Yes
Input Connectors	HDMI, DisplayPort, SDI
Output Connectors	HDMI, DisplayPort, SDI
Maximum Resolution	4K/UHD at 60Hz
Redundancy	Optional
Control	Web UI
