Barco MVSP10 - Introduction; Parts, Controls and Connectors; Front

Introduction
12
Introduction
The MVSP10 (Medical Video Switcher and Processor) video interface is
intended as an interface between different video sources from
different modalities and is generating a single video format to be
connected to standard displays equipped with a DVI-D interface. The
interface is facilitating the cabling and is providing all required image
processing to convert the applied video formats into the single video
output format. 2 Ethernet interfaces allow controlling the video
interface remotely and also provide a frame grabber function to a
workstation.
Parts, controls and connectors
Below is a description of the default parts, controls and connectors
configuration.
Front
Figure 1: Parts, controls and connectors (front)
1
2
3
4
5
7
8
6
9
10
11
12-14
15
