Barco MVSP10 - Page 15

Introduction
15
CAT6 1 input (LIVE
IN)
DVI-I 1B output
DVI-I 2B output
CAT6 1A output
CAT6 2A output
Ethernet 1 con-
nector
Ethernet 2 con-
nector
Functional GND
connector
Power input
Power switch
USB 0 connector
N° Description Lay-out
2
3
4
5
6
7
8
9
10
11
I
O
12
