Manual 2100-200
Page 2
WALL MOUNT GENERAL INFORMATION
Air Conditioner Wall Mount Model Nomenclature
WA241–A10X XXXXA
VOLTS & PHASE
A - 230/208/60/1
B - 230/208/60/3
C - 460/60/3
MODEL
NUMBER
REVISIONS
CAPACITY
18 - 1 1/2 Ton
24 - 2 Ton
KW
VENTILATION OPTIONS
X - Barometric Fresh Air Damper
(Standard)
B - Blank-off Plate
M - Motorized Fresh Air Damper
V - Commercial Room Ventilator -
Motorized with Exhaust
E - Economizer (Internal - Fully
Modulating with Exhaust
R - Energy Recovery Ventilator -
with Exhaust
FILTER OPTIONS
X - One Inch Throwaway
(Standard)
W- One Inch Washable
P - Two Inch Pleated
COLOR OPTIONS
X - Beige (Standard)
1 - White
2 - Mesa Brown
4 - Buckeye Gray
5 - Desert Brown
6 - Dark Bronze
CONTROL MODULES
COIL OPTIONS
X - Standard
1 - Phenolic Coated Evaporator
2 - Phenolic Coated Condenser
3 - Phenolic Coated Evaporator
and Condenser
OUTLET OPTIONS
X - Front (Standard)
T - Top on WA30 and WA36
Models
NOTE: For 0KW and circuit breakers (230/208 Volt) or pull disconnects (460 Volt) applications, insert 0Z in the KW field of model number.
TABLE 1
ELECTRIC HEAT TABLE
sledoMAW181A-AW42A-1B-142AW
1-V0421-V8021-V0421-V8023-V0423-V802
WKSPMAHUTBSPMAHUTBSPMAHUTBSPMAHUTBSPMAHUTBSPMAHUTB
47.61056,314.41042,01
58.02560,711.81008,218.02560,711.81008,21
83.33003,728.82574,023.33003,728.82574,02
016.14031,432.63006,526.14031,432.63006,52
0.6 4.41005,025.21063,51
0.9 7.12006,037.81030,32
