Instruction, Use and Maintenance Manual
EN-IST-BBZP-0418
DN80 and DN100
Weight between 25 kg and 50 kg
DN125 and DN150
Weight over 50 Kg
BBZP
Size
DN
Weight
Kg
10-65 A
80-100 B
125-150 C
DN10 and DN65
Weight lower to 25 kg
3. VALVE LIFTING:
Take care as to the type of valve you are handling. Based on the size
there are two different lifting procedures.
CAUTION!
Before lifting the valve, make sure there are no disassembled or
separate valve parts which could fall off causing injury to persons
and damage to the valve.
CAUTION!
The figures above are used purely to represent the methods and procedures for hoisting the valves.
Bardiani Valvole S.p.A. declines all liability for any damage to things and/or injuries to persons caused
by improper and/or incorrect hoisting of the valve.
11
A
B
C
