Instruction, Use and Maintenance Manual
EN-IST-BBZP-0418
INDEX
1 Safety,Warning and Mandatory Signs 5
2 General safety warnings 8
3 Technical data 9
4 Checking / Unpacking / Lifting 10
5 Installation 12
6 Operation 15
7 Troubleshooting 16
8 Cleaning 17
9 General maintenance 18
10 Scheduled maintenance 20
11 Tools useful for Disassembly/Reassembly 21
12 Pneumatic valves BBZP - BBZR - BBZT- BBYP - BBYR - BBYT 22
13 Disassembly of the BBZP - BBZR - BBZT - BBYP - BBYR - BBYT 24
A Disassembly of the BBZP - BBZR - BBZT - BBYP - BBYR - BBYT 25
B Disassembly of the BBZP P7-LL 29
14 Assembly of the BBZP - BBZR - BBZT - BBYP - BBYR - BBYT 36
A Assembly of the BBZP - BBZR - BBZT - BBYP - BBYR - BBYT 42
B Assembly of the BBZP P7-LL 46
15
Pneumatic Valves BBZP - BBZR - BBZT- BBYP - BBYR - BBYT Diverters 50
16 Disassembly of the BBZP - BBZR - BBZT- BBYP - BBYR - BBYT Diverters 53
A Disassembly of the BBZP - BBZR - BBZT- BBYP - BBYR - BBYT Diverters 54
B Disassembly of the BBZP M8-LLL Diverter 59
17
Assembly of the BB ZP - BBZR - BBZT- BBYP - BBYR - BBYT Diverters 66
A Assembly of the BB ZP - BBZR - BBZT- BBYP - BBYR - BBYT Diverters 72
B Assembly of the BBZP M8-LLL Diverter 77
18 Pneumatic Valves BBZT - BBYT 81
19 Disassembly of the BBZT - BBYT 83
20 Assembly of the BBZT - BBYT 87
21 Annexes 94
22 2D diagram BBZP 95
23 2D diagram BBZP M8-LL 96
24 2D diagram BBZP P7-LL 97
25 2D diagram BBZR 98
26 2D diagram BBZT 99
27 2D diagram BBYP 100
28 2D diagram BBYR 101
