61-101-00802.EF1 Revision J Page | 20
Note: Do NOT spray contact cleaner on the individual Matrix type connectors.
c. If cleaning the connectors does not yield satisfactory results, it may become
necessary to de-pin and inspect each Matrix type connector. Replace any
matrix type blocks that are suspect.
Note: When cleaning the connectors be sure to include the T/S’s connectors.
(60) Set the T/S ON / OFF switch to OFF.
E. Disconnecting/Reconfiguring
(1) Open the circuit breakers, turn the battery switch OFF.
CAUTION: WHEN LOWERING OR RAISING THE FUEL PANEL, ENSURE THE
AIRCRAFT BATTERY SWITCH IS OFF AND BATTERY IS
DISCONNECTED.
(2) Disconnect T/S from the aircraft wiring.
(3) Disconnect T/S from the Indicator.
(4) Reconnect aircraft wiring plug to Indicator.
(5) Return the aircraft to its original configuration.
