MODEL SR124
TRACKING WITH RADIO REMOTE CONTROL (Optional Extra)
The radio remote is an independent control unit for the tracks only
• First plug in the Receiver Box connection. The machine will not track if the receiver box is not plugged in. Always unplug the
dog lead remote control.
• Start the engine / machine.
• Push the two levers of the drive control up fully.
• After the remote tracking manual handset has been disconnected from the machine press any button on the transmitter.
• There will be a short delay and then the transmitter becomes active.
• Before transporting, always check that the machine is secure and there are no loose objects or material.
• Always use the appropriate vehicle for hauling the sceener. Take into consideration the weight and size of the machine and
the route when transporting.
• Check local regulations of transporting large machinery i.e. certification.
8) OPERATING THE DIESEL POWERED MACHINE CONTINUED
