12
Section C – Chimney Surround & Roof
1. Centre the recess panel on the
mantle and lay out the first layer of
the wall surround. Quarry stone sits in
recess panel notch in all 5 layers.
Adjust as needed. Glue this layer
down using the included landscape
glue, except for the recess panel in
case you want an access point to the
chimney.
8 x 12 (4) 4 x 8 (4)
8 x 8 (3) 4 x 4 (2)
IMPORTANT: Periodic checks must
be made to ensure that the layers
remain level. If layers are not level, use the
included shims to adjust as necessary. Fill
any large gaps between the quarry stone
with the included silicone.
2. Lay out the second layer of the wall
surround as indicated in the diagram.
8 x 12 (6)
8 x 8 (2)
4 x 4 (2)
3. Repeat the patterns from Steps
1&2 to a height of 5 layers above
the mantle, checking the layers
remain level. Glue the 5th layer down
using the included landscape glue.
IMPORTANT: Allow glue to set for at
least 2 hours before installing the roof.
Check to ensure the glue has begun to
set so that the roof does not move any
blocks underneath. Blocks should be
steady when moved.
Match distance from
back edge with
quarry stone beneath
the mantle.
8”x12”
8”x8”
4”x8”
4”x4”
4”x4”
8”x12”
8”x8”
To Next Page
