Barko 295B - Model Description: 295 B SE Specifications; 295 B SE Model Specifications

13-2
®
MODEL DESCRIPTION- 295B SE
SPECIFICATIONS
Maximum Lift Capacity: 22,820 lbs
Vertical Reach: 36’ -9”
4. Tail Swing: 8’-6” without counterweight
Total Operating Weight: 25,000 lbs without attachment or cw
Horizontal Reach: 30’
8’-8” with optional 1,300 lb counterweight
8’-10” with optional 3,000 counterweight
Swing Torque: 30,000 ft-lbs
295B Stationary Electric (SE)
3. Overall Width: 8’-5”
1. Overall Height: 11’-4”
2. Overall Length: 38’ 4” with 30’ boom extended
1. Height: 33”
2. Top Plate: 35.5” diameter
3. Bottom Plate: 39” diameter
Bottom Holes: (30) - 1-3/8” dia holes eq spaced on a 34.5” dia circle
295B Stationary Electric (SE) - Pedestal
3
1
2
1
34
2
07/26/2018
Updated
