Barracuda CloudGen Firewall - F600 Standard and C20 Model Port Configuration

Barracuda CloudGen Firewall
Barracuda NG Firewall F600 Revision C 2 / 8
F600 sub-model .F20
F600 sub-model .E20
The standard model of Barracuda's NG Firewall F600 (Rev. C) comes with twelve 10/100/1000 MBit
RJ45 Ethernet ports and a single power supply. Other F600 model types (.C20, .F10 and .E20) provide
different port combinations and options for dual power supply.
F600 Standard Model (.C10) and Sub-Model .C20 Port Configuration
Label OS Notation Speed/Type Management Port
1 port1 10/100/1000 MBit RJ45 X
2 port2 10/100/1000 MBit RJ45
3 port3 10/100/1000 MBit RJ45
4 port4 10/100/1000 MBit RJ45
5 port5 10/100/1000 MBit RJ45
6 port6 10/100/1000 MBit RJ45
7 port7 10/100/1000 MBit RJ45
8 port8 10/100/1000 MBit RJ45
9 port9 10/100/1000 MBit RJ45
10 port10 10/100/1000 MBit RJ45
11 port11 10/100/1000 MBit RJ45
12 port12 10/100/1000 MBit RJ45
