5 Technical specifications
5.1 General data
5.2 Electrical data
6 Mounting
For dimensions and mounting see “Zeichnungen / Drawings / Dessins”
page 11.
7 Commissioning
Before commissioning make sure that:
• the appliance has been mounted according to instructions,
• the electrical connections have been carried out correctly,
• the right fuse in accordance with 5.2 has been installed,
• the appliance is not damaged in any way.
8 Servicing
The appliance is maintenance-free
9 Cleaning
Zone 1:
• Clean only with a damp cloth using water or mild non-chafing, non-
scratching cleaning fluid. Never use aggressive substances or solvents
when cleaning.
Zone 21:
• Clean with a cloth, brush, vacuum-cleaner or similar. For wet cleaning use
water or mild non-chafing, non-scratching cleaning fluid. Never use
Material PC, black
Dimensions 178 mm x 207 mm x 104 mm
Weight 1500 g
Sound pressure max. 105 dB
Temperature range -40 °C ... + 50 °C
Duty cycle 70%
Protection type according to IEC 60529 IP 65
Explosion protection for gas
II 2G Ex e mb IIC T5 Gb
Explosion protection for dust
II 2D Ex tb IIIC T70°C Db
Test certificate BVS 05 ATEX E 113X
Type Rated current Voltage range Current
consumption
Fuse to be
connected in series
07-4602-1112 24 V= 21,6 ... 26,4 V 350 mA F 0,5 A
07-4602-1212 24 V~, 50 Hz 21,6 ... 26,4 V 450 mA F 0,63 A
07-4602-1312 42 V - 48 V~, 50 Hz 37,8 ... 52,8 V 220 mA F 0,315 A
07-4602-1412 115 V~, 50/60 Hz
120 V~, 60 Hz
102,5 ... 126,5 V
108 ... 131 V
205 mA
220 mA
F 0,315 A
07-4602-1512 230 V~, 50 Hz 208 ... 250 V 70 mA F 0,125 A
