1. Remove the steering handles and fold the seat
down. Locate the transport pins on the front and
back of the chassis.
2. Angle the transporter so that the frame is almost
vertical.
3. Roll the transporter over the machine, aligning the
transporter brackets with the pins. Slide the
brackets under the pins.
4. Bring the handle down and fit the pickup bar on
the lowest ring of the chassis.
5. Slide the hitch pin into the pickup bar to secure it
on the ring. Attach the cotter pin to the bottom of
the hitch pin.
6. Use the handle to transport the Ride-On Trowel.
