Bartell B1318 - CUSTOMER PARTS LIST (Exciter Assembly)

VIBRATORY PLATE COMPACTORS INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
25 INDUSTRIAL DRIVE, KEYPORT, NEW JERSEY, USA, 07735, 732-566-5400 FAX 732-566-5444
Created: 11/10
Revised: 06/13
- 19 -
CUSTOMER PARTS LIST
Assembly #
30129, 30077, 30076
(Small, S-model, L & H model) Exciter Assembly
Item #
B1318
S
Model
L & H
Model
Description Qty Eff. Date
1 30047 30047 30047 Bearing #NJ308EG1C3 2 12/02/04
2 30164 30163 30162 Shaft Ass’y 1 12/02/04
3 10610 10610 10610 Oil Seal 1 12/02/04
4 10911 10911 10911 Pipe Plug, Sq. Hd.,3/8-18 1 12/02/04
5 30010 30010 30010 SHCS 1/4-20 x 1/2 UNC 4 12/02/04
6 30016 30016 30016 Retaining Ring, N5000-400 2 12/02/04
7 30027 30027 30027 O-Ring, #224, Fluorocarbon 4 12/02/04
8 30028 30028 30028 O-Ring, #224, Fluorocarbon 4 12/02/04
9 30044 30044 30044 Flange 1 12/02/04
10 30045 30045 30045 End Cap 1 12/02/04
11 30125 30025 30025 Mechanical Tube 1 12/02/04
12 10987 10987 10987 Dowel Pin, 3/16”Dia. x 1/2”LG 2 12/02/04
