Bartell B424 - Page 24

Created: 07/04
Revised: 08/14
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444
- 24 -
Item # Part Number Description Qty. Eff. Date
1 21611 Lower Handle 1 1/1/1997
21625 Lower Handle (CE Spec.) 1 1/1/1997
2 21601 Upper Handle 1 8/1/2007
3 10508 Throttle Assembly, Cable c/w Lever 1 8/1/2007
4 11848 Hand Knob 1 1/1/1997
5 11852 Safety Switch 1 1/1/1997
6 11836 RHMS M5 - 0.8 x 10mm 2 1/1/1997
7 10703 Lock Washer, Internal Tooth, #10 Dia 2 1/1/1997
8 11483 HHCS M8 - 1.25 x 110mm 1 1/1/1997
9 21631 Lever Nut 1 1/1/1997
10 11667 Flat Washer, M8 2 1/1/1997
11 20552 Tube w/Spring 2 1/1/1997
12 11617 Nylock Nut, M8 1 1/1/1997
14 11641 Handle Grip, Left 1 2/1/2008
15 11642 Handle Grip, Right 1 2/1/2008
16 21628 Hand Knob Assembly 1 2/1/2008
17 11771 Rod 1 2/1/2008
18 11622 Hex Nut, 10mm 3 2/1/2008
19 11633 Yoke 1 2/1/2008
20 11818 Clevis Pin 1 2/1/2008
21 11819 Cotter Pin 1 2/1/2008
22 10521 Lock Washer, 1/4” 1 2/1/2008
23 14446 HHCS, M6-1x12mm 1 2/1/2008
CUSTOMER PARTS LIST
Figure 4 - Handle Assembly Parts List (not part of 21632)
Figure 4 - Folding Handle Assembly Parts List (21632)
24 11615 Hex Nut, M8-1.25 1 2/1/2008
25 11614 Lock Washer, M8 1 2/1/2008
26 11854 Bracket, Upper 1 2/1/2008
27 11763 Carriage Bolt, M8-1.25x25mm 1 2/1/2008
28 11622 Hex Nut, 10mm 1 2/1/2008
29 11621 Lock Washer, M10 1 2/1/2008
30 41516 Flat Washer, M10 1 2/1/2008
31 11853 Bracket, Lower 1 2/1/2008
