EDGER TROWEL INSTRUCTION MANUAL
BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
25 INDUSTRIAL DRIVE, KEYPORT, NEW JERSEY, USA, 07735, 732-566-5400 FAX 732-566-5444
Created: 07/04
Revised: 06/12
CUSTOMER PARTS LIST
Assembly # Edger
Assembly
Item # B424 B430 Description Qty Eff. Date
1 11660 11660 Bearing, Needle Roller 1 6/8/2004
2 11628 11628 Bearing 1 6/8/2004
3 11770 11770 Gearbox 1 6/8/2004
4 21612 21612 Folding Handle Ass’y 1 6/8/2004
5 11752 11752 Engine Mounting Plate 1 6/8/2004
6 21340 21333 Honda Engine 1 6/8/2004
8 21006 21006 Clutch 1 6/8/2004
9 21616 11815 Spider Plate Ass’y 1 6/8/2004
10 20455 20407 Trowel Blade, Combo 4 6/8/2004
11 11769 11769 SHCS M8 x 16mm 4 6/8/2004
12 11758 11813 Stabilizer Ring, 1 6/8/2004
13 11755 11755 Main Shaft, 1 6/8/2004
14 11639 11639 Key, 8mm x 7mm x 50mm LG 1 6/8/2004
15 11756 11756 Pressure Plate 1 6/8/2004
16 11652 11810 Rotating Ring, 1 6/8/2004
17 11640 11812 Belt, Rotating Ring (T-Belt) 1 6/8/2004
18 11631 11631 Retaining Ring 1 6/8/2004
19 11632 11632 Retaining Ring 1 6/8/2004
20 11774 N/A Friction Washer 1 6/8/2004
21 52180 N/A FHMS 10-24 x 3/8”LG 2 6/8/2004
22 11775 11775 Wave Washer 1 6/8/2004
23 11655 11655 Thrust Bearing Cap 1 6/8/2004
24 11672 11672 Yoke Arm 1 6/8/2004
25 10306 10306 Washer 1 6/8/2004
26 10104 10104 Spacer 4 6/8/2004
27 11740 11740 Set, Pin Support LH + RH 1 30/4/2007
28 30041 30041 FHSCS 5/16-24 UNF x 3/4" 2 6/8/2004
29 30042 30042 Clutch Retainer Washer 1 6/8/2004
30 11622 11622 Hex Nut 10mm 1 6/8/2004
32 11665 11665 Stud 1 6/8/2012
34 11638 11638 Key, 6mm SQ x 25mm LG 1 6/8/2004
35 11662 11662 Belt Guard 1 6/8/2004
36 11669 11669 Belt Guard Support Bracket 1 6/8/2004
37 10402 10402 Lock Washer, 5/16" 2 6/8/2004
38 10409 10409 HHCS 5/16-18 x 1/2”LG 2 6/8/2004
39 10206 10206 Key, 3/16"Sqx1 7/8"LG 1 6/8/2004
40 11685 11685 Pulley, 4.5" DIA X 3/4" BORE 1 6/8/2004
41 50117 50117 SHSS, 5/16-18x0.57UNC, CUP POINT 2 6/8/2004
42 11007 11007 V-Belt 4L-260 1 6/8/2004
43 11646 11646 Yoke Pin 1 6/8/2004
44 11645 11645 Retaining Ring, 5100-0031 2 6/8/2004
Continued on next page…
- 21 -
Item # B424 B430 Description Qty. Eff. Date
1 11660 11660 Bearing, Needle Roller 1 6/8/2004
2 11628 11628 Bearing, Thrust 1 6/8/2004
3 11770 11770 Gearbox 1 6/8/2004
9 21616 11815 Spider Plate Assembly 1 6/8/2004
10 20455 20407 Trowel Blade, Combo 4 6/8/2004
11 11769 11769 SHCS M8 x 16mm 4 6/8/2004
12 11758 11813 Stabilizer Ring 1 6/8/2004
13 11755 11755 Main Shaft 1 6/8/2004
14 11639 11639 Key, 8mm x 7mm x 50mm LG 1 6/8/2004
15 11756 11756 Pressure Plate 1 6/8/2004
16 11652 11819 Rotating Ring 1 6/8/2004
17 11640 11812 Belt, Rotating Ring (T-Belt) 1 6/8/2004
18 11631 11631 Retaining Ring 1 6/8/2004
19 11632 11632 Retaining Ring 1 6/8/2004
20 11774 11774 Friction Washer 1 6/8/2004
21 11836 52180 FHMS 10-24 x 3/8” LG 2 6/8/2004
23 11655 11655 Thrust Bearing Cap 1 6/8/2004
24 11672 11672 Yoke Arm 1 6/8/2004
27 11659 11659 Set, Pin Support LH + RH 1 30/4/2007
34 11638 11638 Key, 6mm SQ vs 25mm LG 1 6/8/2004
43 11646 11646 Yoke Pin 1 6/8/2004
44 11645 11645 Retaining Ring, 5100-0031 2 6/8/2004
45 11614 11614 Lockwasher, M8, Split, Din 127, Zinc Plated 12/01/2004
46 11619 11619 HHCA M8-1.25 x 25mm, Zinc Plated 2 12/01/2004
51 10521 10521 Lock Washer, 1/4” 8 12/01/2004
51a 14446 14447 Washer, 6mm 1 12/01/2004
52 12532 10523 HHCS 1/4-20 x 1-1/2”LG / M6-1.00 x 35mm 8 12/01/2004
53 11765 11765 Retainer Plate 1 12/01/2004
54 11772 11772 SHCS M8-1.25 x 25mm 1 12/01/2004
55 11627 11627 Bearing 61808 2RS 1 12/01/2004
56 11766 11811 Float Plan 1 12/01/2004
57 11767 11767 Retainer 1 12/01/2004
58 11753 11752 SHCS M10 x 1.5 x 35mm 1 12/01/2004
CUSTOMER PARTS LIST
Figure 2 - Full Bottom Assembly Parts List
