SPECIFICATIONS
TECHNICAL INFORMATION
B424, B430 EDGER TROWEL
Overall Dimensions (WxHxL)
Shipping Dimensions
Shipping Weight
29 1/2” x 58 1/2” x 36” (750mm x 1490mm x 910mm)
39” x 40” x 31” (1000mm x 1020mm x 790mm)
157 lbs (71 kg) ~ B424
192 lbs (87 kg) ~ B430
Blade Speed (RPM)
Engine Speed (RPM)
70 min – 125 max
3600
Clutch Type
Variable Speed
Centrifugal
Yes
Gearbox Oil
Gearbox Oil Capacity
Engine Fuel
Engine Oil Alert
Cooling
Starting
Shell Tivela Compounds A or similar type
10.1 oz. (0.3 L.)
Gasoline – Unleaded
Yes
Air
Recoil Starter - Manual
Dead-man Safety Switch
Fuel Capacity (approximately)
Running Time (approximately)
Yes
0.66 Gal. (2.5 L)
2 ½ - 3 hours
Number of Blades 4
Average acoustic power (dB)
Average acoustic pressure (dB)
Acoustic pressure on operator (dB)
Vibration value on the handle (aw)
103.2
88.8
89.1
7.0
Options Hoist Hook
Folding Handle
¥ Power rating conforming to DIN 6270 & ISO 3048/1 Std.
¥ RPM results may vary by engine option.
Model Path
Power Source
(gas option)
Float
Blade Size
Finish
Blade Size
Combination
Blade Size
Pans
Flaots
Pans
Flaots
Operating
Weight
B424
(Edging)
24"
(60 cm)
4 hp Honda OHV
4 hp Robin OHV
N/A
4.75” x 9"
(12 x 23 cm)
N/A
24"
(60 cm)
138 lbs.
63 kg
Up to 110 lbs.
(50 kg)
B430
(Edging)
30"
(76 cm)
5.5 hp Honda OHV
6 hp Robin OHV
10” x 30"
(25 x 28 cm)
6” x 10.5"
(15 x 26 cm)
6” x 10"
(15 x 25 cm)
30"
(76 cm)
184 lbs.
84 kg
Up to 145 lbs.
(66 kg)
