Connection scheme of electromechanical lock
using third party power supply
+12V
DC
Electromechanical
lock
-
+
LAN (PoE)
1 2 3
+12V 485+
RS485 / Exit Button / Door Sensor
4 5
GND EXIT485-
6
DS
7 8
DINFIN
1 2 3
+12V NC
Supply / Relay Outputs
4 5
GND NOCOM
1 2 3
+5V WD0
Wiegand Out
4
GND WD1
SH-42
(optional)
SH-45
Door Sensor
Exit Button
GND
+12V
+12V
DC
-
+
Connection scheme of electromagnetic lock
using third-party power supply
+12V
DC
Electromagnetic Lock
-
+
LAN (PoE)
1 2 3
+12V 485+
RS485 / Exit Button / Door Sensor
4 5
GND EXIT485-
6
DS
7 8
DINFIN
1 2 3
+12V NC
Supply / Relay Outputs
4 5
GND NOCOM
1 2 3
+5V WD0
Wiegand Out
4
GND WD1
SH-42
(optional)
SH-45
Door Sensor
Exit Button
GND
+12V
+12V
DC
-
+
